Input (DC)
Max. PV array power | 1430 Wp STC |
Max. input voltage | 500 V |
MPP voltage range / rated input voltage | 70 V to 450 V / 360 V |
Min. input voltage | 70 V |
Initial feed-in voltage | 90 V |
Max. operating input current per MPPT | 11 A |
Max. short circuit current per MPPT / per string input | 16.5 A / 16.5 A |
Number of independent MPPT inputs / strings per MPPT input | 1 / 1 |
Output (AC)
Rated power | 1000 W |
Max. apparent AC power | 1100 VA |
AC nominal voltage | 220 V / 230 V / 240 V |
AC voltage range | 180 V to 280 V |
AC grid frequency / range | 50 Hz / 45 Hz to 55 Hz 60 Hz / 55 Hz to 65 Hz |
Rated grid frequency / rated grid voltage | 50 Hz / 230 V |
Max. output current | 5.5 A |
Power factor at rated power | 1 |
Adjustable displacement power factor | 0.8 overexcited to 0.8 underexcited |
Feed-in phases | 1 |
Harmonic distortion (THD) at rated output | < 3% |
Efficiency
Max. efficiency / European efficiency | 97 % / 96.3 % |
Protective devices
Input-side disconnection device | ● |
Ground fault monitoring / grid monitoring | ● / ● |
DC reverse polarity protection / AC short circuit current capability | ● / ● |
All-pole-sensitive residual-current monitoring unit | ● |
Protection class (according to IEC 62109-1) / overvoltage category (according to IEC 62109-1) | I / AC : III ; DC : II |
General data
Dimensions (W / H / D) | 346 / 346 / 132 mm |
Weight | 6.5 kg |
Operating temperature range | -25 ℃ to +60 ℃ |
Noise emission (typical) | < 15 dB(A) |
Self-consumption (at night) | < 1 W |
Topology | Transformerless |
Cooling concept | Convection |
Degree of protection (according to IEC 60529) | IP65 |
Climatic category (according to IEC 60721-3-4) | 4K4H |
Max. permissible value for relative humidity (non-condensing) | 100% |
Max. operating altitude | 4000 m (>3000m derating) |
Features
DC connection | SUNCLIX |
AC connection | Plug-in connector |
Mounting type | Wall mounting bracket |
Display | 16 x 2 characters LCD |
LED Indicators (Status / Fault / Communication) | ● |
Interface: RS485 / WLAN & Ethernet 1) & 2) | ○ / ○ |
Certificates and approvals (more available on request) | CE, EN50438, G83/2, VDE-0126, VDE-AR-N4105, AS/NZS 4777, C10/C11, VFR 2014 & UTE C15, TOR D4 V2, CNS15382, IEC62109, IEC62116, IEC61727, IEC61683, IEC60068 |
● standard
○ optional
- not available
1) Zero export installations supported with 2-pin RS485 for connection to approved smart meters
2) DRED supported with analog RJ45 interface for Australia & New Zealand
As of December, 2018 / Technical data is subject to revisions.
Input (DC)
Maximum PV array power (STC) | 2140 Wp |
Maximum DC power at cosφ=1 | 1750W |
Max. input voltage | 500V |
MPP voltage range / rated input voltage | 70-450V / 360V |
Min. start voltage | 80V |
Min. feed-in power | 20W |
Max. input current per MPPT | 11A |
Number of MPPTs | 1 |
Number of independent MPP inputs | 1 |
Output (AC)
Rated active power | 1500W |
Max. apparent AC power | 1650VA |
Nominal AC voltage / range | 220V, 230V, 240V / 180-280V |
AC power frequency / range | 50, 60 / +-5Hz |
Rated power frequency / rated grid voltage | 50Hz / 230V |
Max. output current | 7.5A |
Power factor (@rated power) | 1 |
Adjustable displacement power factor | 0.8 inductive ... 0.8 capacitive |
Feed-in phases / connection phases | 1 / 1 |
Harmonic distortion (THD) at rated output | < 3% |
Efficiency
Max. efficiency / European weighted efficiency | 97.2% / 96.5% |
MPPT efficiency | 99.5% |
Protective devices
DC isolator | ○ |
PV iso / Grid monitoring | ● / ● |
DC reverse polarity protection / AC short-circuit current capability | ● / ● |
GFCI function | ● |
Protection class (according to IEC 62103) / Overvoltage category (according to IEC 60664-1) | I / II(DC), III(AC) |
General data
Interfaces: RS485 / RS4851 & Ethernet & WIFI & a.RJ452(DRED) | ● / ○ |
Earth Fault Alarm3 | cloud based, audible and visible |
Display | 16 x 2 characters |
Dimensions (W x H x D) | 346 x 346 x 132mm |
Weight | 6.5kg |
Cooling concept | Convection |
Noise emission (typical) | < 15 dB(A)@1m |
Installation | Indoor & Outdoor |
Mounting information | Wall mounting bracket |
DC connection technology | SUNCLIX |
AC connection technology | Screw clamp terminal |
Operating temperature range | -25℃ ... +60℃ / -13℉ ... +140℉ |
Relative humidity (non-condensing) | 0% ... 100% |
Max. operating altitude | 4000m (> 3000m derating) |
Degree of protection (according to IEC 60529) | IP65 |
Climatic category (according to IEC 60721-3-4) | 4K4H |
Topology | transformerless |
Self-consumption (night) | < 1W |
Standby power | < 6W |
12-pin RS485 for connection to approved smart meters in zero export installations (replacing standard RS485 on RJ 45 connector)
2Analog RJ45 interface to DRED in Australia & New Zealand
3Selectable in ZeverCloud; audible alarm will only be activated in AS4777 setting
● standard
○ optional
- not available
As of October, 2017 / Technical data is subject to revisions.
Input (DC)
Max. PV array power | 2860 Wp STC |
Max. input voltage | 500 V |
MPP voltage range / rated input voltage | 70 V to 450 V / 360 V |
Min. input voltage | 70 V |
Initial feed-in voltage | 90 V |
Max. operating input current per MPPT | 11 A |
Max. short circuit current per MPPT / per string input | 16.5 A / 16.5 A |
Number of independent MPPT inputs / strings per MPPT input | 1 / 1 |
Output (AC)
Rated power | 2000 W |
Max. apparent AC power | 2200 VA |
AC nominal voltage | 220 V / 230 V / 240 V |
AC voltage range | 180 V to 280 V |
AC grid frequency / range | 50 Hz / 45 Hz to 55 Hz 60 Hz / 55 Hz to 65 Hz |
Rated grid frequency / rated grid voltage | 50 Hz / 230 V |
Max. output current | 10 A |
Power factor at rated power | 1 |
Adjustable displacement power factor | 0.8 overexcited to 0.8 underexcited |
Feed-in phases | 1 |
Harmonic distortion (THD) at rated output | < 3% |
Efficiency
Max. efficiency / European efficiency | 97.3 % / 96.7 % |
Protective devices
Input-side disconnection device | ● |
Ground fault monitoring / grid monitoring | ● / ● |
DC reverse polarity protection / AC short circuit current capability | ● / ● |
All-pole-sensitive residual-current monitoring unit | ● |
Protection class (according to IEC 62109-1) / overvoltage category (according to IEC 62109-1) | I / AC : III ; DC : II |
General data
Dimensions (W / H / D) | 346 / 346 / 132 mm |
Weight | 6.5 kg |
Operating temperature range | -25 ℃ to +60 ℃ |
Noise emission (typical) | < 15 dB(A) |
Self-consumption (at night) | < 1 W |
Topology | Transformerless |
Cooling concept | Convection |
Degree of protection (according to IEC 60529) | IP65 |
Climatic category (according to IEC 60721-3-4) | 4K4H |
Max. permissible value for relative humidity (non-condensing) | 100% |
Max. operating altitude | 4000 m (>3000m derating) |
Features
DC connection | SUNCLIX |
AC connection | Plug-in connector |
Mounting type | Wall mounting bracket |
Display | 16 x 2 characters LCD |
LED Indicators (Status / Fault / Communication) | ● |
Interface: RS485 / WLAN & Ethernet 1) & 2) | ○ / ○ |
Certificates and approvals (more available on request) | CE, EN50438, G83/2, VDE-0126, VDE-AR-N4105, AS/NZS 4777, C10/C11, VFR 2014 & UTE C15, TOR D4 V2, CNS15382, IEC62109, IEC62116, IEC61727, IEC61683, IEC60068 |
● standard
○ optional
- not available
1) Zero export installations supported with 2-pin RS485 for connection to approved smart meters
2) DRED supported with analog RJ45 interface for Australia & New Zealand
As of December, 2018 / Technical data is subject to revisions.
Input (DC)
Max. PV array power | 3900 Wp STC |
Max. input voltage | 600 V |
MPP voltage range / rated input voltage | 70V to 520 V / 360 V |
Min. input voltage | 70 V |
Initial feed-in voltage | 150 V |
Max. operating input current per MPPT | 11 A |
Max. short circuit current per MPPT / per string input | 16.5 A / 16.5 A |
Number of independent MPPT inputs / strings per MPPT input | 1 / 1 |
Output (AC)
Rated power | 3000 W |
Max. apparent AC power | 3000 VA |
AC nominal voltage | 220 V / 230 V / 240 V |
AC voltage range | 180 V to 280 V |
AC grid frequency / range | 50 Hz / 45 Hz to 55 Hz 60 Hz / 55 Hz to 65 Hz |
Rated grid frequency / rated grid voltage | 50 Hz / 230 V |
Max. output current | 15 A |
Power factor at rated power | 1 |
Adjustable displacement power factor | 0.8 overexcited to 0.8 underexcited |
Feed-in phases | 1 |
Harmonic distortion (THD) at rated output | < 3% |
Efficiency
Max. efficiency / European efficiency | 97.5 % / 97 % |
Protective devices
Input-side disconnection device | ● |
Ground fault monitoring / grid monitoring | ● / ● |
DC reverse polarity protection / AC short circuit current capability | ● / ● |
All-pole-sensitive residual-current monitoring unit | ● |
Protection class (according to IEC 62109-1) / overvoltage category (according to IEC 62109-1) | I / AC : III ; DC : II |
General data
Dimensions (W / H / D) | 346 / 346 / 146 mm |
Weight | 6.8 kg |
Operating temperature range | -25 ℃ to +60 ℃ |
Noise emission (typical) | < 15 dB(A) |
Self-consumption (at night) | < 1 W |
Topology | Transformerless |
Cooling concept | Convection |
Degree of protection (according to IEC 60529) | IP65 |
Climatic category (according to IEC 60721-3-4) | 4K4H |
Max. permissible value for relative humidity (non-condensing) | 100% |
Max. operating altitude | 4000 m (>3000m derating) |
Features
DC connection | SUNCLIX |
AC connection | Plug-in connector |
Mounting type | Wall mounting bracket |
Display | 16 x 2 characters LCD |
LED Indicators (Status / Fault / Communication) | ● |
Interface: RS485 / WLAN & Ethernet 1) & 2) | ○ / ○ |
Certificates and approvals (more available on request) | CE, EN50438, G83/2, VDE-0126, VDE-AR-N4105, AS/NZS 4777, C10/C11, VFR 2014 & UTE C15, TOR D4 V2, CNS15382, IEC62109, IEC62116, IEC61727, IEC61683, IEC60068 |
● standard
○ optional
- not available
1) Zero export installations supported with 2-pin RS485 for connection to approved smart meters
2) DRED supported with analog RJ45 interface for Australia & New Zealand
As of December, 2018 / Technical data is subject to revisions.
